Working mode

Auto

Loads per hour

Up to 45

Rotation speed

Up to 12rpm (adjustable)

Maximum load size

1400mm Lx 1500 mm x 2300 mm H

Wrapping method

Bottom, middle and top wrapping layer can be set from 0-99 winds

Film (LLDPE)

Thickness 0.02mm, width 500mm, length 500m-1500m, weight: 15kg

Film capacity

500mm width x 76mm dia

Pre-stretch type

Strain gauge

Pre-stretch level

250% (optional 100% to 300%)

Force control

Variable

Film threading

Jinglin design, W film threading pattern

Cut and seal

Controlled impulse cutter and heat sealer

Controller

Siemens PLC

Tension control

Magnetic controller

Operator interface

Touch screen/ separate buttons

Load height sensor

Photo eye

Wrap settings

Re-wrap function, overwrap and overlap adjustments

Wrap counters

Independent top and bottom

Cycle counters

Total cycle counter and resettable counter

Emergency stop

Red mushroom head

Electrical disconnect

Lockable

Electrical enclosure

European approved

Voltage

380 VAC, 3 phase 5 wires, 50 Hz. (adjustable)

Pneumatic

6-8kgf/cm² (clean, dry air)

Bearing type

Ring gear

Start & stop mode

Soft start & stop

Diameter

1500mm

Maximum turning diameter

2000mm

Maximum load weight

1500kg

Turntable elevation

110mm
